4 / 9
SWIVEL HOUSING AND STEERING CYLINDER
Pos.
Ref.
Q.tyDescrizione
Description
Kit
From S/N To S/N Note
*
Q.tyvalid only for one steering arm assy.
TAB. - 2.0.0
REVISION DATE - 00/00
P/N: CA355201
1
1 Calotta SX
Swivel housing LH
2
2 Bronzina
Bush
3
2 Anello di tenuta
Oil seal kit
4
2 Dado M16
Nut M16
5
2 Vite M16x100
Bolt M16x100
6
16 Vite M12x30
Bolt M12x30
7
4 Ingrassatore M6x1
Grease nipple M6x1
8
2 Perno snodo
King pin
9
8 Tappo
Plug
10
1 Calotta DX
Swivel housing RH
11
2 Perno snodo
King pin
12
1 Asta di guida DX
Steering arm assy RH
13
1* Snodo sferico
Ball joint
14
1* Dado M18x1.5
Nut M18x1.5
15
1 Tirante snodo DX
Tie rod RH
16
2 Dado M18x1.5
Nut M18x1.5
17
4 Vite M16x70
Bolt M16x70
18
2 Vite M16x90
Bolt M16x90
19
2 Bussola
Bush
20
1 Martinetto
Cylinder assy
21
1 Asta di guida SX
Steering arm assy LH
22
1 Tirante snodo SX
Tie rod LH
23
2 Testata cilindro
Cylinder head
24
1 Stelo completo
Rod
25
1 Kit guarnizioni
Seal kit
130587
125390
123208
022129
124748
126921
024210
128904
030782
130588
128903
130594
350054
022183
350735
022437
021250
021202
139110
126765
130593
350960
049042
049051
049043
AXLE 20.11 REF.139783
16
17
19
20
13
14 12
15
22
14 21
13
16
18
1
2
3
4
5
6
7
8
9
10
11
7
6
23
24
25
23
